ZSS系列水泥振動篩產品概述

    ZSS系列水泥振動篩系國內首創，結構獨特新穎，打破傳統設計方案，采用振動電機作激振源，物料進行拋擲運動，達到篩分處理的目的，改掉了磙筒篩和連桿往復篩的堵篩 、粘網、換網難的缺點。ZSS系列水泥振動篩廣泛用于篩出水泥 石灰及類似的粉狀物料的異物，以保證輸送設備和包裝的安全運轉。ZSS系列水泥振動篩具有結構先進，體積小，重量輕，效率高，噪音低，采用新型的振動電機作直接驅動。

Product overview
   ZSS series vibrating screen is a cement at first in China, a unique and novel structure, break traditional design scheme of adopting vibration motor as vibration source, materials are throwing motion, to achieve the purpose of the screening process, get rid of the stone drum sieve and linkage reciprocating screen wall screen, screen, the shortcoming of difficult to replace the network.Sieve out ZSS series vibrating screen is widely used in cement cement lime powder materials and similar foreign body, to ensure the safe operation of conveyor equipment and packaging.ZSS series cement vibrating screen with advanced structure, small volume, light weight, high efficiency, low noise, the new type of vibration motor for direct drive.

ZSS系列水泥振動篩主要特點

1.改機結構先進,體積小,重量輕,效率高,噪音低,采用新型的振動電機做直接驅動。
2.篩網結構簡單,維修方便,篩網采用高度強度金屬編織網,經久耐用。
3.改機坐式和吊掛式均可。

Features
1. Change machine advanced structure, small volume, light weight, high efficiency, low noise, using new type of vibration motor for direct drive.
2. The screen has simple structure, convenient maintenance, USES the high strength metal mesh weaving nets, durable.
3. Change machine sitting and hanging type.

ZSS系列水泥振動篩型號說明
Model specification
Z S　S □ □
┬ ┬ ┬ ┬ ┬
│ │ │ │ │　
│ │ │ │ └──────────　篩面長度1/10mm
│ │ │ │
│ │ │ └───────────-　篩面寬度1/10mm
│ │ │
│ │ └─────────────　振動篩
│ │　
│ └──────────────-　水泥成品
│
└────────────────　直線運動

ZSS系列水泥振動篩技術參數表

Parameters

型號

篩面

給料粒度

處理量(t/h)

振次r.p.m

雙振幅

方  向  角

振動電機

外型尺寸長×寬×高

重量  (kg)

面積

傾角(度)

篩孔尺寸  (mm)

結構

型號

功率

ZSS615

0.9

6

5×5

編織

<20

5－15

960

6

50

YZDP 5－6

0.4×2

1700×1145×1120

305

ZSS815

1.2

15－35

1700×1410×1150

420

ZSS1020

2

35－50

7

YZDP 10－6

0.75×2

2238×1160×1350

758

ZSS1224

2.88

50－75

8

YZDP 20－6

1.5×2

2488×2010×1500

1180
